SL-802W

Overview

• SL-802W is designed as HGU (Home Gateway Unit) in deferent FTTH solutions; the carrier-class FTTH application provides data service access.

• SL-802W is based on mature and stable, cost-effective XPON technology. It can switch automatically with EPON and GPON mode when it access to the EPON OLT or GPON OLT.

• SL-802W adopts high reliability, easy management, configuration flexibility and good quality of service (QoS) guarantees to meet the technical performance of the module of China Telecom EPON CTC3.0.

• SL-802W is compliant with IEEE802.11n STD, adopts with 2x2 MIMO, the highest rate up  to 300Mbps.

• SL-802W are fully compliant with technical regulations such as ITU-T G.984.x and IEEE802.3ah.

• SL-802W is designed by Realtek chipset 9602C

Feature

• Supports Dual Mode (can access GPON/EPON OLT).

• Supports GPON G.984/G.988 standards

• Support 802.11n WIFI (2x2 MIMO) function

• Support NAT, Firewall function.

• Support Flow & Storm Control , Loop Detection, Port Forwarding and Loop-Detect

• Support port mode of VLAN configuration

• Support LAN IP and DHCP Server configuration

• Support TR069 Remote Configuration and WEB Management

• Support Route PPPoE/IPoE/DHCP/Static IP and Bridge mixed mode

• Support IPv4/IPv6 dual stack

• Support IGMP transparent/snooping/proxy

• In compliant with  IEEE802.3ah standard

• Compatible with popular OLT (HW, ZTE, FiberHome...)

Specifications
